GENERAL PARAMETER
|
||
|
Display & Control
|
LCD, 4 Button Control
|
|
|
WiFi Extension & APPs
|
USB Hardware, Solar of Things
|
|
|
Operating Temp. Range
|
-10ºC ~ +55ºC
|
|
|
Operating Humidity Range
|
5% ~ 95%
|
|
|
Operating Altitude Range
|
2000m (derate above 2000m)
|
|
|
Cooling Method & Noise Level
|
Fan Cooling; ≤50db
|
|
|
Installation Method
|
Wall-wounted
|
|
|
Inverter Size (L*W*H)
|
350*290*105 mm
|
|
|
Net Weight
|
6 kg
|
|
|
Package Size
|
495*385*165 mm
|
|
|
Gross Weight
|
7 kg
|
|
|
Warranty Period
|
3Years
|
|
|
Standards & Certifications
|
EN 62109-1:2010; EN 62109-2:2011;EN 61000-3; EN 61000-6;
IEC 61683:1999; GB/T 4208-2017 |
|
|
BATTERY PARAMETER (BAT +/- Terminal)
|
||
|
Battery Type
|
LiFePO4 / Lead-Acid
|
|
|
Battery Voltage Range
|
20~30Vdc
|
|
|
Rated Voltage
|
24Vac
|
|
|
Max. Charge/Discharge Current
|
120A / 180A
|
|
|
BMS Communication Mode
|
RS485
|
|
